We are committed to providing customers with high-quality and low-cost products. We have different types of products to meet the needs of different customers. We have four leading products. Our products are best sold not only in the Chinese market, but also welcomed in the international market.
Microbulk is a modern concept where your gas is supplied by filling on-site vs. the traditional method by handling numbers of empty cylinders and dewars. Microbulk enjoys outstanding features mean exceptional performance.
Victank microbulks benefits:
It is an on-site filling solution for gas cylinder users.
The charge loss is low or even zero.
Longer liquid gas hold times.
Extraordinary thermal quality assures very little gas loss.
The boost speed is fast and the gas flow is large.
Quick recharge to save time and reduce costs.
Multiple pressures, different volumes, more choices.
Brand valves HEROSE, REGO, accessories, high reliability.
Small footprint, convenient transportation, simple installation.
Less operation and maintenance needed.
ASME standard 5000L-24bar | MC5000HP | |
MAWP | Mpa(psi) | 2.4(350) |
Max. Pre-set Operating Press | Mpa(psi) | 1.8(260) |
Gross Volume | L(gal) | 5168(1365) |
Net Volume | L(gal) | 4910(1297) |
NER(Nitrogen) | %/Day | 0.4 |
Tare Weight | kg(lbs) | 2855(6294) |
Gaseous Volume(CO2) | Nmˆ3(SCF) | 3147(111137) |
Gas delivery rate | Nmˆ3/H(SCFH) | 40(1413) |
Pallet Width "A" | mm(inch) | 2100(82.67) |
Pallet Length "B" | mm(inch) | 2100(82.67) |
Tank Diameter "D" | mm(inch) | 1910(75.2) |
Overall Height "H" | mm(inch) | 3150(124.02) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
4units 1m3 microbulk tank shipped by one 20FT container.
3units 2m3 microbulk tank shipped by one 20OT container. (open top container)
3units 3m3 microbulk tank shipped by one 20OT container. (open top container)
2units 5m3 microbulk tank shipped by one 20OT container. (open top container)
Our company sticks to the principle of "Quality is the life of the company, and reputation is the soul of it" for 1m3 lox storage of oxygen in zambia - Victank, The product will supply to all over the world, such as: Liberia, Mauritania, US, Wellington, With the technology as the core, develop and produce high-quality merchandise according to the diverse needs of the market. With this concept,the company will continue to develop merchandise with high added values and continuously improve items,and will present many customers with the best goods and services!
