Bear "Customer first, High quality first" in mind, we perform closely with our consumers and provide them with efficient and experienced services for We're self-assured to create wonderful achievements while in the potential. We've been hunting forward to becoming one of your most trustworthy suppliers.
Microbulk enable small and medium volume users to enjoy the benefits of on-site gas delivery. MicroBulk Storage Systems provide reliable, efficient and economical solutions for liquid nitrogen, oxygen, argon, CO2, N2O, and LNG.
Designed to replace high pressure gas cylinders, VICTANK eliminates:
• waste and expense of full for empty gas cylinders
• cylinder change-overs
• residual gas losses
• lost or damaged cylinders
• cylinder inventory management
• manual handling injuries
Horizontal microbulk tank is suitable for general container loading and also for where the installation space limited by the height.
ASME standard 5000L-35bar | MBH5000VHP | |
MAWP | Mpa(psi) | 3.5(500) |
Max. Pre-set Operating Press | Mpa(psi) | 3.1(450) |
Gross Volume | L(gal) | 5031(1329) |
Net Volume | L(gal) | 4629(1223) |
NER(Nitrogen) | %/Day | 0.6 |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 3695(130502) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 2976(105101) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 3615(127658) |
Gas delivery rate | Nmˆ3/H(SCFH) | 100(3532) |
Pallet Width "A" | mm(inch) | 3150(124.01) |
Pallet Length "B" | mm(inch) | 1400(55.12) |
Tank Diameter "D" | mm(inch) | 1910(75.2) |
Overall Height "H" | mm(inch) | 2150(84.64) |
Width w/piping "w" | mm(inch) | 2230(87.8) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1units shipped by 1x20GP container.
3units shipped by 1x40GP container.
The relentless pursuit of perfection． Hot sale 1m3 n2 storage of oxygen supplier - Victank, The product will supply to all over the world, such as: Norway, Sevilla, Mumbai, European, Our staffs are adhering to the "Integrity-based and Interactive Development" spirit, and the tenet of "First-class Quality with Excellent Service". According to the needs of every customer, we give customized & personalised services to help customers achieve their goals successfully. Welcome clients from home and abroad to call and inquire!
