MicroBulk is a cost-effective gas management solution that provides the efficiencies of bulk delivery to smaller volume users of nitrogen, oxygen, argon and carbon dioxide.
Eliminate hassles. Reduce costs. Increase safety. Microbulk solutions are ideal for businesses with growing demands for industrial gases.
ASME standard 3000L-16bar | PCT3000MP | |
MAWP | Mpa(psi) | 1.6(230) |
Max. Pre-set Operating Press | Mpa(psi) | 1.0(150) |
Gross Volume | L(gal) | 3031(801) |
Net Volume | L(gal) | 2789(737) |
NER(Nitrogen) | %/Day | 0.7 |
Tare Weight | kg(lbs) | 1700(3748) |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 2226(78623) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 1793(63320) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 2178(76910) |
Pallet Width "L" | mm(inch) | 3400(133.86) |
Pallet Length "W" | mm(inch) | 1800(70.87) |
Tank Diameter "D" | mm(inch) | 1508(59.37) |
Overall Height "H" | mm(inch) | 1900(74.80) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1unit shipped by 1x20GP container.
3units shipped by 1x40GP container.
